广东腾宏机械科技有限公司

1. 機器操作使用油壓操作系統。
2. 各組左右爪子可以設定自動下拉行程或手動操作升降，讓鞋面的張力平衡，以修正結幫最佳位置。
3. 內撐台上升高度，由機台外部調整,高度數值同時顯示於觸控銀幕。
4. 鞋頭壓著機構採用可調二段式壓力，使鞋子於結幫過程中及最後之壓著能達到最佳之效果，壓頭的一次壓并可視鞋面材質不同，可選用定壓及定位之兩種壓著方式，使結幫更順暢。
5. 中爪可依鞋頭形狀作左右各15°之偏調整，適合特殊鞋型爪盤的排列。
6. 第五爪具向內旋轉功能，旋轉角度可視需求調整，使鞋面於結幫時更貼楦。
7. 本機附有十字投影燈裝置，方便鞋頭校正與定位。

FEATURES

1. Fully hydraulic operated system.
2. Each set of pincers (left and right) can be setting with automatic pulling or manual operated ,preventing the upper made of different marterials is only pulled on one side.
3. The upward stroke of the last support can be adjusted from the knob outside the machine,and the setting value will be displayed in the screen.
4. Toe cap pressing mechanism adopts adjustable two-stage pressure to enable the shoes achieves the best effects in the bonding process and the final pressing .The lst stroke of pressure valve can select the pressing modes of the constant pressure and the positioning pressure depending on the vamp materials to make the lasting more smoothly.

   5.     The middle pincer can be adjusted for yawing to be left and to the right within 15°each side according to the toe cap shape ,suitable for special shoe models and pincers assembly arrangement.

   6.    The fifth pincer has the function of inward rotation,the rotation angle adjustment is depending on the demands, and enabling the shoe more fit the shoe last when lasting.

    7.   The machine is accompanied with the align light device to facilitate the toe cap correction and position.

          厂家直销，欢迎前来订购！
