华颖机械有限公司

下图为装货配送图

用途特点：

适用于成型刀模冲裁各种鞋面、鞋底、皮革、橡胶、化纤、硬纸及棉织品、
1、设有自动供油润滑系统、减少磨损，延长使用寿命‘
2、采用电子延时电路控制冲程下限位置，精度高，可提高制鞋品质，利用手
轮调节摆臂距工作台高度，简单、可靠、方便
    It is used to cut uppers, soles, rubber, plastic, chimicalfibbre,hard psper,ect
a.lt is equiped vith a lubricating sysfem,to reduce wear and prolong Its service  life
A.elecironic time-lapse system can better quell of shoes and
makes operation simply.convenient and tavle
B.the position of the swing arm is adjusted by the upper handwheel on the machine
blanking travel is controlled by the timer,thus it is easy to
obtaom the best cutting position.which can increasework efficiency and prolong
the service life of the knife mould and 6ecking board
型号
最大冲裁力
摆臂宽度
冲程调节范围
冲裁速度
上、下工作台面使用距离
下工作台面尺寸
电机功率
GSO-2C/20            GSB-2C/25
200KN                    250KN
350 x 550mm          450 x 550mm
5-75mm                  5-75mm
0.10m/s                   0.10m/s
            65-150mm
            1000 x 500mm
              1.5KW
