型号Model
|
XL-4400-1H
|
XL-4400-1HR
|
XL-4400-2H
|
XL-4400-2HQ
|
|
最高缝速
Max. sewing speed
|
2000S.P.M
|
|
线迹长度Stitch length
|
0-10MM
|
|
针杆行程 Needle bar stroke
|
36MM
|
|
挑线杆行程Thread take-up lever stroke
|
74.5MM
|
|
压脚提升Presser foot lift
|
手动（By hand） 8MM 膝控(By knee) 16MM
|
气动 16MM Pneumatic
|
|
机针Needle type
|
DP*17 22#-24#
|
|
针间距Needle gauge
|
标准(Standard)12.7MM 特殊(Special) 9.5MM
|
|
缝台位置Bed type
|
左缝台Left side stitching bed
|
右缝台Right side stitching bed
|
-----------------------------------------------------
|
|
缝台高度Highness of post-bed
|
178MM
|
|
压脚交互量Presser foot alternation
|
2-6MM
|
|
旋梭 Rotating hook
|
手动加油水平大旋梭
Manual lubricated horizontal large rotary hook
|
|
润滑方式Lubrication
|
半自动润滑 Semi-auto lubricated
|
|
汽动抬压脚装置Safety Clutch Device
|
否 No
|
是 Yes
|
|
汽动倒缝装置Manual reverse feeding device
|
否 No
|
是 Yes
|
|
电动机Motor
|
370瓦缝纫机专用电机1400转/分
370W Clutch motor 1400S.P.M
|
550瓦伺服电机
550W Servo motor
|
