性能特点
1、全封闭静音设计,机台周围1米范围内噪音在75db以下,同时避免了粉尘污染
2、外形美观、大方有多种款式以供选择；
3、独特设计内部导热系统，在保持全封闭的前提下，将电机所生产的热量排出机外，延长电机使用寿命；
4、不锈钢储料箱清洗方便、快捷，也可配备带吸料口(不锈钢)型储料箱；
5、内设安全保护系统，可选配CE认证电器，完全符合欧洲安全标准；
6、配有相序控制器，可防止因电机反转所造成的不良后果；
7、装有电源离开光，维修、操作更方便、安全；
8、活动不锈钢料斗、手柄开光等人性化设计，使得操作时得心应手、轻松自如。
Performance&characteristic
1、Fully airtigtht silent desihned,noise below 75db within 1
meter away from the machine,avoids power contamination
simultan eously;
2、Elegant designed with optional available;Installed with
heat transmitting system,expel heat generatedfrom theele
ctric motor ,protection and safety without any problem for
long hours operation;
3、Stainless steel material storage tank easy for cleaning &re-
move,stainless steel suciton spout are available upon require;
4、Installed with safety protection system &power isolator,
safety operation and simple main-tence;
5、Installed with power is olator,safety opration and simple
maintenance;
6、Movable stainless steel multi-posotional tray feed & closed
for complete soudproof operation
技术参数 SPECIFICATIONS
型号 Model | HA-2300A | HA-2300B | HA-2300C | HA-2300D | 粉碎口径 Crushing Chamber(mm) | 310x200 | 410x235 | 515x290 | 610X320 | 粉碎能力 Crushing Abilitt(kg/h) | 150-200 | 200-250 | 300-350 | 350-450 | 固定力 Stationary Cutter | 2 | 2 | 2 | 4 | 旋转刀 Rotary Cutter | 9 | 12 | 15 | 18 | 功率 Power | KW | 5.5 | 7.5 | 11 | 15 | HP | 7.5 | 10 | 15 | 20 | 外型尺寸 Dimensions(lxwxhcm) | 115x72x129 | 103x84x139 | 123x101x163 | 132x111x183 | 净重 Net Weight(kg) | 432 | 500 | 500 | 1100 |
|
