ANSI-Z41,CSA-Z195,GB12011
本机在测试鞋底或绝缘鞋材所能承受的电压值,以了解其耐电压程度。试验方法是施加电压于鞋底,并将电压缓慢上升至规定值,检查鞋底是否能够在一定的时间内承受该规定的电压。
This tester is used to determine the isolation character of the shoe material.By slowly increase the voltage on the sole to the specified value,check if it can withstand that value in the prescribed time period.
测试电压Test Voltage |
上升速度1kv/sec ,到指定电压75%时,速度自动切换成100V/S |
容量Capacity |
0.5KVA |
输入电压Input Voltage |
AC220V |
输出电压Output Voltage |
AC 20 KV |
测试空间Test Space |
58×38×54cm |
体积Dimension |
121×48×75cm |
重量Weight |
85kg |
电源Power |
1∮,AC220V, 10A |
