祥瑞热熔胶机公司

主要技术参数 Main Technical PARAMETERS
●TANK容量：7kg
●帮浦功率：齿轮90W-40K
●操作温度：最高210℃
●整体耗电量：2600W
●电力需求：220VAC/单相
●出胶功率：54kg/hr
●机体重量：45kg
●风压范围：枪体：4.5kg
●融胶能力：11kg/hr,3000CPS
●机体尺寸：520X350x630
◆TANK CAPACITY:7kg
◆PUMP POWER:Gear Pump 90w-40k
◆OPERATING TEMPERATURES:MAX 210℃
◆POWER CONSUMPTION:2600W
◆OPERATING POWER:220VAC/single phase
◆EJECTING CAPACITY:54kg/hr
◆WEIGHT:45kg

◆WIND PRESSURE RANGE:Inside cylinder:4,5kg
◆MELTING CAPACITY: 11kg/hr,3000CPS
◆DIMENSION: LxWxH 520x350x 630
功能特点 Functions and features
●Gearpump高强度铝合金成型、耐磨。出胶持久性佳、寿命长。
●电路故障检知：维持机器使用效率并使热融胶品质稳定。
●控温精度准确，TANK分上、中、底层各别控温，PID温度差±1℃降低碳化机会。
●可依TANK容量选择帮浦系统，或预约订购特殊容量。
◆The Gear pump made of aluminium alloy of high intensity is wearresisting producs endurable adhesive and has long service life.
◆It checks up the circuit breakdown: keeps the machine efficient to make the hot melt adhesive stable.
◆It controls the temperature accurately, the tank is divided into upper,middle and lower beds, whose temperatures are separately controlled.PID temperature difference 10±1℃ reduces possible carbonization.
◆You can choose bump sets by tank capacity or place an order for special capacity.
