1、自动进出模设计，安全，便捷，节省人工成本。
Automatic mold entry and exit design, safe, convenient and save labor costs.
2 、机身采用国标40mm铁板经激光切割，经高温消除应力后加工而成；
The fuselage adopts the national standard 30mm iron plate to be cut by laser, and then processed by high temperature to
eliminate stress;
3 、油缸采用球墨铸件，活塞采用冷硬铸铁，耐磨不易刮伤；
The cylinder is made of ductile castings, and the piston is made of chilled cast iron, which is wear-resistant and not easy to
be scratched;
4、油箱设置水冷却功能，降低油温，延长循环油寿命;
The oil tank is equipped with a water cooling function to reduce the oil temperature and prolong the life of the circulating
oil;
5、采用PLC可编程控制，带密码分级锁止功能。五国语言高清触摸屏，带故障侦测提示，使用直观便捷；
Adopt PLC programmable control, with password grading locking function. High-definition touch screen in five languages,
with fault detection prompts, intuitive and convenient to use;
6、采用快升、快降设计，速度达传统结构的两倍；
The design of fast rise and fall is adopted, and the speed is twice that of the ordinary traditional structure;
7、主机液压系统采用伺服三联泵高流量系统，高速响应，精准稳定；
Hydraulic system adopts servo triple pump high-flow system, high-speed response, accurate and stable;
8、电热机型温控仪带通信功能，无需独立设定，温度集中于人机介面操作，密码分级锁止功能；
The electric heating type temperature controller has a communication function, no independent setting is required, the
temperature is centralized on the man-machine interface, and the password is graded to lock;
型号 Product model
|
马达功率
Motor power
|
额定电压
Rated voltage
|
加热方式
heating
|
油缸
Cylinder
|
热板
Hot plate
|
层数
Floors
|
间距
spacing
|
重量Host weight
|
机械尺寸
size
|
|
TH-RB-180T
|
20KW
|
AC 380V
|
蒸汽、热煤油、电加热
Steam, hot kerosene，
Electric heating
|
Φ320mm
|
460*500mm
|
2
|
200mm
|
13000kg
|
L7500*W2400*H1950mm
|
